| Pressure Range |
50 - 150bar 100 - 300bar |
| Maximum Pressure (Pmax) |
500bar |
| Switch Adjustability |
Adjustable |
| Working Principle |
Piston / Spring Loaded |
| Membrane Type |
HBNR / PFTE |
| Switch Status |
NO / NC / Variable |
| Power Supply |
42V / 220V , 2A |
| Operating temperature |
-30... +100°C |
| Protection Class |
Terminal IP00, Other IP65 |
| Switch Frequency |
100 Switch / minute |
| Switch Capacity |
100VA |
| Switch Return Sensitivity |
±%5 |
| Standard Connection Thread Sizes |
Male G1 / 4 '' |
| Optional |
1/8 '' taper, 1/8 '' NPT, M12x1.5 or on request |
| Body Material |
Automat Steel, Optional Brass or Stainless Steel |
